T8451 ICS TRIPLEX data sheet


Brand: ICS Model:T8451
Package/Specification: 2x19x12.8cm
Minimum Packaging Quantity: 1

Function: Control system accessories Features: Easy installation
Name: Digital Input Module Processing Customization:
Origin: USA Packaging: brand new and
widely used
Chemical, papermaking, power
generation, oil and natural gas
Quantity: 1-999
Batch Number T8451

Available for sale in Beijing; Tianjin; Hebei;
Shanxi; Inner Mongolia; Liaoning; Jilin;
Shanghai;Jiangsu; Zhejiang; Anhui; Fujian; Jiangxi; Shandong; Henan;
Hubei; Hunan; Guangdong; Guangxi; Hainan;
Chongqing; Sichuan Guizhou; Yunnan; Xizang
Shaanxi Gansu; Qinghai; Ningxia; Xinjiang

Purpose TMR redundant structure

  • Phone:+86 17750010683
  • Whatsapp:+8617750010683


T8451 ICS TRIPLEX data sheet
T8451 ICS TRIPLEX data sheet
Module Clips Drive controller servo moto

The ICS TRIPLEX T8451 Digital Input Module is a critical component specifically designed for industrial automation and process control systems, produced by ICS Triplex (now part of Honeywell Process Solutions).

This module has a series of advanced functions and features that enable it to play an important role in various industrial environments.

Firstly, the T8451 digital input module has comprehensive automatic diagnosis and self checking functions. This means that it can monitor the status
and performance of modules in real-time, ensuring the stable operation of the system. This automatic diagnostic function greatly improves the reliability and safety of the system.

Secondly, the module has configurable digital input channels. Users can configure input channel parameters based on actual needs, such as over acceleration
threshold. This flexibility enables the T8451 digital input module to adapt to various application scenarios.

In addition, the T8451digital input module also has high reliability. It uses high-quality materials and advanced production processes, and undergoes strict
quality control and testing to ensure stability and reliability in critical applications.

In order to improve system availability, some T8451modules also have redundant input channels. This means that when one input fails, it can be switched to
a backup input to ensure the continuous operation of the system. This redundancy greatly improves the system”s fault tolerance and reliability.

In addition, the T8451 digital input module also has strong anti-interference and anti-interference capabilities. This enables it to work stably in complex
industrial environments without being affected by external interference.

In terms of specific applications, the ICS TRIPLEX digital input module has been widely used in multiple fields. In the power system, it can be used to monitor
digital signals such as the status, current, and voltage of power equipment to ensure the stability and safety of the power grid.

In the chemical industry, the T8451 digital input module can be used to monitor key parameters in chemical processes, ensuring the safety and efficiency
of the production process. In the oil and gas industry, this module can be used to monitor and control various parameters in the oil and gas production process,

Ensure the normal operation of the equipment.

Contact: Mr. Lai
Whats app:+86 17750010683
Skype:+86 17750010683
QQ: 3221366881

Practical application of ABB industrial information control system 800xA in main shaft hoist control

The mine hoist is an important transportation equipment for mining enterprises. Its main function is to transport the ore, personnel or equipment that need to be transported to the destination by the lifting container. Therefore, it plays a very important role in the mining production process. Usually the mine hoist control system consists of a driving part and a control part. The working mechanism of the driving part is: the motor unit drives the mechanical hoisting device, and the frequency converter or other types of hoisting control systems drive the motor unit: the working mechanism of the control part is: Each component of the hoist is coordinated and controlled by the Distributed Control System (DCS). In addition to completing basic process control, it can also integrate intelligent instruments, intelligent transmission and motor control, and even production management and safety systems into one operation and engineering environment. middle. Therefore, the mine hoist requires a control system with high performance, high reliability, and high integration.

1ABB800xA system and AC800M controller introduction

1.1ABB800xA system introduction

The 800xA system is an industrial information control system launched by ABB. The core of its architecture is object-oriented (ObjectOriented) technology. Due to the adoption of ABB’s unique Aspect0object concept, enterprise-level information access, object navigation and access can become standardized and simple.

In order to provide a unified information platform for enterprise managers and technical personnel, the 800xA system provides a base platform (BasePlatform), which relatively separates the process control part and production control management and organically combines them together. As shown in Figure 1, the middle part is the basic platform, the upper part is the production control management part, and the lower part is the process control part. The basic platform provides standard interfaces for these two parts for data exchange.

1.2 Introduction to ABBAC800M controller and its programming configuration tools

AC800M controller is ABB’s latest controller series, which includes a series of processors from PM851 to PM865. The AC800M controller itself has a pair of redundant TCP/IP interfaces. It can use the MMs protocol to communicate with other control devices and 800xA operator stations through Ethernet. It can also use the Modbus protocol and Point-Point protocol through 2 serial ports. communication. The programming and configuration tool of AC800M is ControlBuilderM, referred to as CBM. It supports standard ladder diagram, function block language, text description language and assembly language to write control logic.

2. Improve the design and implementation of control system functions

2.1 Implementation of elevator operating speed curve

One of the main tasks of the lifting control system is to control the lifting motor to operate according to the speed-position curve given by the design, so that the lifting container passes through the acceleration section, the uniform speed section and the deceleration section successively, and stops accurately after completing the specified lifting distance. somewhere in the wellbore. In order to realize the function of precise position calculation, the designed elevator control system must be able to perform high-precision position calculation based on the photoelectric encoder connected to the main shaft of the elevator drum. The calculation formula is as follows:

In the formula, s is the actual position value of the elevator: sp is the distance corresponding to two consecutive encoder pulses: AN is the difference between the encoder count value at the reference position and the current position (signed variable): s0 is the reference position value.

The encoder counts are distributed according to the circumference of the drum. After the number of pulses Np generated by the encoder rotation is known, the diameter of the circumference of the centerline of the wire rope wrapped around the drum must be accurately known, so that it can be calculated according to formula (2) The distance sp corresponding to the two encoder pulses:

In the formula, D is the circumferential diameter of the centerline of the wire rope: Np is the number of pulses for one revolution of the known encoder.

But in formula (2), there is a value D that keeps getting smaller as the system runs. This is because the wire rope used in the elevator is wrapped around the drum, and there is a lining between the wire rope and the drum that increases friction. This liner will become thinner and thinner as the system continues to wear and tear, causing the diameter of the circle formed by the center line of the steel wire rope to gradually become smaller. When the pad wears to a certain extent, it will cause a large position calculation error. In order to solve the above problems, the two parking position switches in the shaft are used to correct the drum diameter, because the distance between the two parking positions can be obtained through actual measurement with high accuracy. During the actual operation, record the encoder count values ​​at the two parking positions respectively. According to formula (3), the actual correction value of sp can be calculated:

In the formula, sd is the distance between two parking positions: Abs is the absolute value operation: N is the encoder count value when there are two parking positions.

In this way, the initial sp value is first set according to the given design parameter value, and then the value is corrected according to the actual operating conditions, which can effectively ensure the accuracy of position calculation. At the same time, sp’ can also be substituted into formula (2), and the D value can be obtained in turn, which can be used as a basis for judging whether the liner is seriously worn.

After obtaining the elevator position value, the speed control curve can be calculated according to formula (4):
