Description
9852 ICS TRIPLEX Industrial Control Module
9852 ICS TRIPLEX Industrial Control Module
Module Clips Drive controller servo moto
The ICS TRIPLEX 9852 Digital Input Module is a critical component specifically designed for industrial automation and process control systems, produced by ICS Triplex (now part of Honeywell Process Solutions).
This module has a series of advanced functions and features that enable it to play an important role in various industrial environments.
Firstly, the 9852 digital input module has comprehensive automatic diagnosis and self checking functions. This means that it can monitor the status
and performance of modules in real-time, ensuring the stable operation of the system. This automatic diagnostic function greatly improves the reliability and safety of the system.
Secondly, the module has configurable digital input channels. Users can configure input channel parameters based on actual needs, such as over acceleration
threshold. This flexibility enables the 9852 digital input module to adapt to various application scenarios.
In addition, the 9852digital input module also has high reliability. It uses high-quality materials and advanced production processes, and undergoes strict
quality control and testing to ensure stability and reliability in critical applications.
In order to improve system availability, some 9852modules also have redundant input channels. This means that when one input fails, it can be switched to
a backup input to ensure the continuous operation of the system. This redundancy greatly improves the system”s fault tolerance and reliability.
In addition, the 9852 digital input module also has strong anti-interference and anti-interference capabilities. This enables it to work stably in complex
industrial environments without being affected by external interference.
In terms of specific applications, the ICS TRIPLEX digital input module has been widely used in multiple fields. In the power system, it can be used to monitor
digital signals such as the status, current, and voltage of power equipment to ensure the stability and safety of the power grid.
In the chemical industry, the 9852 digital input module can be used to monitor key parameters in chemical processes, ensuring the safety and efficiency
of the production process. In the oil and gas industry, this module can be used to monitor and control various parameters in the oil and gas production process,
Ensure the normal operation of the equipment.
Contact: Mr. Lai
Wechat:17750010683
Whats app：+86 17750010683
Skype：+86 17750010683
QQ: 3221366881
3221366881@qq.com
Implementation of communication between ABC industrial robot and PLC based on DeviceNet fieldbus technology
introduction
In modern production systems, industrial robots and PLCs need to communicate and collaborate to complete production tasks. That is, the industrial robots output signals to the PLC, allowing the PLC to control related equipment to drive the robot’s front-end tools. This article mainly analyzes the communication problems between ABB industrial robots and PLC based on DeviceNet fieldbus technology. DeviceNet is a common network communication method in the field of automation. ABB industrial robots establish a network to communicate with Siemens PLC based on the DeviceNet network.
1Configure DSQC652
There are mainly 5 types of standard I/0 boards commonly used in ABB industrial robots [2]. Except for the different addresses assigned to them during setup, their configuration methods are basically the same. This article mainly analyzes the ABB standard I/0 board DS0C652, which mainly builds communication modules based on the DeviceNet network. The DS0C652 board has a distributed I/O module with 16 digital input and 16 digital output interfaces. The board is installed in the ABB industrial robot control cabinet. First, define the specific operation steps of the DS0C652 board, enter the teach pendant control panel, then enter the configuration menu (Figure 1), select the DeviceNetDevice menu, and add a template to enter Figure 2. ABB standard I/0 board is hung on the DeviceNet network, so the address of the module in the network must be set. The jumpers 6 to 12 of terminal x5 are used to determine the address of the module. The available address range is 10 to 63. Modify the parameters in the template parameters to complete the DS0C652 board settings. Click the drop-down menu to select the “Use value from template” row, select “DS0C65224VDCI/0Device”, and then the parameters that need to be set include the address of the I/0 board in the bus.
Figure 1 Configuring DSQC652
2Configure signals and parameters
After completing the DS0C652 board setting, the I/0 signal setting will be performed. Setting the I/0 signal is the basis for establishing communication with the PLC. The PLC communicates and transmits data with the ABB industrial robot through the I/0 signal and the DS0C652 board. As shown in Figure 3, in the signal configuration interface, there are many default I/0 points after the system is established. Modification is not allowed. Click “Add” to add signals. When setting input and output signals, their address range is 0~15. First, enter the signal menu in the configuration options to set the input and output types, and modify the corresponding parameters. After completing the settings, the computer prompts that you need to restart the settings. If there are multiple signals that need to be defined and the waiting time is long after restarting multiple times, you can click “Cancel” and wait for all signals to be defined before clicking the “Yes” button to restart. After the signal settings are completed, click to select “Input and Output” in the ABB menu to check whether all signals have been set.
Figure 2 Configure DSQC652 parameters
Figure 3 Signal parameter settings
During the signal establishment process, attention should be paid to the DSoC652 port and PLC port addresses used, and the corresponding address table should be established, as shown in Table 1. The robot interacts with the PLC through I/O signals. During the setting process, there must be no errors in the port and address number of the PLC connected to the DSoC652. If the address is set incorrectly, the communication between the robot and the PLC will not work properly.
The entire robot teaching pendant setting process is shown in Figure 4.
